Hydrogenation Catalyst for Purifying H2 Production

Hydrogenation Catalyst for Purifying H2 Production has many excellent characteristics as follows,

1. Mo-Co-Ni ternary active components, alumina- titania composite carrier.

2. Excellent activity and stability.

3. High mechanical strength and structure stability.

4. Low light off temperature, can be used alone in adiabatic for the high olefin feedstock.

5. Enables start-up without pre-sulfiding, shorten star-up time.


Product introduction

Application of hydrogenation catalysts for purifying H2 production

1. Used in hydrogenation purification process of H2 production feedstock for olefin saturation and organic sulfur conversion.

2. AMC-YJ-01/AMC-YJ-03 suitable for purifying natural gas, coking dry gas, catalytic dry gas, hydrogenation dry gas, naphtha etc., feedstock, loaded in adiabatic reactor.

3. AMC-YJ-02 suitable for purifying natural gas, coking dry gas, catalytic dry gas, hydrogenation dry gas, naphtha etc., feedstock, especially thpse H2 production feedstock with high olefin content, such as catalytic dry gas. It can be filled in adiabatic reactor or column tabular reactor.



Product Basic Info

Operating conditions of hydrogenation catalyst for purifying H2 production


Item

AMC-YJ-01

AMC-YJ-02

AMC-YJ-03

Temperature/℃

180~400

160~400

180~400

Pressure/MPa

1.0~5.0

1.0~5.0

1.0~5.0

Olefin Content, %

≤8

≤30

≤8

Organic sulfur content/ppm

≤300

≤300

≤300

Space velocity/h-1

≤3000

≤3000

≤3000



Product Specification

Physical and chemical properties of hydrogenation catalysts for purifying H2 production


Item

AMC-YJ-01

AMC-YJ-02

AMC-YJ-03

Color and shape

Grey-green Spherical

Grey-green clover extrudate

Grey-green clover extrudate

Size/mm

Φ3.5~5.5

Φ2~3

Φ2~3

Active components

Mo-Co-Ni

Mo-Co-Ni

Mo-Co-Ni

Carrier

Al2O3-TiO2

Al2O3-TiO2

Al2O3-TiO2

Bulk density/(kg.L-1)

0.70~0.90

0.50~0.65

0.50~0.65

Crushing strength

≥80(N.granula-1)

≥130(N.cm-1)

≥130(N.cm-1)
